Image is for reference only , See Product Specifications
MAL229957152E3
| Manufacturers: | Vishay BC Components |
|---|---|
| Product Category: | Aluminum Electrolytic Capacitors |
| Data Sheet: | MAL229957152E3 |
| Description: | CAP ALUM 1500UF 20% 450V SNAP 4L |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Vishay BC Components |
| Product Category | Aluminum Electrolytic Capacitors |
| Series | 299 PHL-4TSI |
| Ratings | - |
| Impedance | 50 mOhms |
| Packaging | Bulk |
| Tolerance | ±20% |
| Capacitance | 1500µF |
| Part Status | Active |
| Applications | General Purpose |
| Lead Spacing | 0.886" (22.50mm) |
| Polarization | Polar |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In - 4 Lead |
| Voltage - Rated | 450V |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Size / Dimension | 1.575" Dia (40.00mm) |
| Height - Seated (Max) | 4.016" (102.00mm) |
| Operating Temperature | -40°C ~ 105°C |
| Surface Mount Land Size | - |
| Ripple Current @ Low Frequency | 5.67A @ 100Hz |
| Ripple Current @ High Frequency | 8.505A @ 10kHz |
| ESR (Equivalent Series Resistance) | 80mOhm @ 100Hz |
In Stock 66 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $51.48 | $50.45 | $49.44 |
