TPH3208LS
| Manufacturers: | Transphorm |
|---|---|
| Product Category: | Transistors - FETs, MOSFETs - Single |
| Data Sheet: | TPH3208LS |
| Description: | GANFET N-CH 650V 20A PQFN |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Transphorm |
| Product Category | Transistors - FETs, MOSFETs - Single |
| Series | - |
| FET Type | N-Channel |
| Packaging | Tube |
| Vgs (Max) | ±18V |
| Technology | GaNFET (Gallium Nitride) |
| FET Feature | - |
| Part Status | Obsolete |
| Mounting Type | Surface Mount |
| Package / Case | 3-PowerDFN |
| Vgs(th) (Max) @ Id | 2.6V @ 300µA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 130mOhm @ 13A, 8V |
| Power Dissipation (Max) | 96W (Tc) |
| Supplier Device Package | 3-PQFN (8x8) |
| Gate Charge (Qg) (Max) @ Vgs | 14nC @ 8V |
| Drain to Source Voltage (Vdss) | 650V |
| Input Capacitance (Ciss) (Max) @ Vds | 760pF @ 400V |
| Current - Continuous Drain (Id) @ 25°C | 20A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
In Stock 88 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $12.25 | $12.01 | $11.76 |
