Image is for reference only , See Product Specifications
UCC27201ADPRR
| Manufacturers: | Texas Instruments |
|---|---|
| Product Category: | PMIC - Gate Drivers |
| Data Sheet: | UCC27201ADPRR |
| Description: | IC DVR HIGH/LOW SIDE 3A 10WSON |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | PMIC - Gate Drivers |
| Series | - |
| Gate Type | N-Channel MOSFET |
| Packaging | Digi-Reel® |
| Input Type | Non-Inverting |
| Part Status | Active |
| Channel Type | Independent |
| Mounting Type | Surface Mount |
| Package / Case | 10-WDFN Exposed Pad |
| Voltage - Supply | 8V ~ 17V |
| Number of Drivers | 2 |
| Driven Configuration | Half-Bridge |
| Operating Temperature | -40°C ~ 140°C (TJ) |
| Rise / Fall Time (Typ) | 8ns, 7ns |
| Supplier Device Package | 10-WSON (4x4) |
| Logic Voltage - VIL, VIH | 0.8V, 2.5V |
| High Side Voltage - Max (Bootstrap) | 120V |
| Current - Peak Output (Source, Sink) | 3A, 3A |
In Stock 2506 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
Request Quote
