Image is for reference only , See Product Specifications
UC3867N
| Manufacturers: | Texas Instruments |
|---|---|
| Product Category: | PMIC - Voltage Regulators - DC DC Switching Controllers |
| Data Sheet: | UC3867N |
| Description: | IC REG CTRLR MULT TOPOLOGY 16DIP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | PMIC - Voltage Regulators - DC DC Switching Controllers |
| Series | - |
| Function | Step-Up/Step-Down |
| Topology | Full-Bridge, Half-Bridge, Push-Pull |
| Packaging | Tube |
| Clock Sync | No |
| Output Type | Transistor Driver |
| Part Status | Active |
| Output Phases | 1 |
| Package / Case | 16-DIP (0.300", 7.62mm) |
| Base Part Number | UC3867 |
| Control Features | Soft Start |
| Duty Cycle (Max) | 100% |
| Number of Outputs | 2 |
| Serial Interfaces | - |
| Output Configuration | Positive |
| Frequency - Switching | 50kHz ~ 500kHz |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Synchronous Rectifier | No |
| Supplier Device Package | 16-PDIP |
| Voltage - Supply (Vcc/Vdd) | 7V ~ 22V |
In Stock 2496 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $6.24 | $6.12 | $5.99 |
Request Quote
