Image is for reference only , See Product Specifications
UC2844ADTR
| Manufacturers: | Texas Instruments |
|---|---|
| Product Category: | PMIC - Voltage Regulators - DC DC Switching Controllers |
| Data Sheet: | UC2844ADTR |
| Description: | IC PWM BUCK BST FLYBCK CM 14SOIC |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | PMIC - Voltage Regulators - DC DC Switching Controllers |
| Series | - |
| Function | Step-Up, Step-Down, Step-Up/Step-Down |
| Topology | Boost, Buck, Buck-Boost, Flyback, Forward |
| Packaging | Digi-Reel® |
| Clock Sync | No |
| Output Type | Transistor Driver |
| Part Status | Active |
| Output Phases | 1 |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
| Control Features | Frequency Control |
| Duty Cycle (Max) | 48% |
| Number of Outputs | 1 |
| Serial Interfaces | - |
| Output Configuration | Positive |
| Frequency - Switching | Up to 500kHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Synchronous Rectifier | No |
| Supplier Device Package | 14-SOIC |
| Voltage - Supply (Vcc/Vdd) | 10V ~ 30V |
In Stock 20665 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
Request Quote
