TPS71501QDCKRQ1
| Manufacturers: | Texas Instruments |
|---|---|
| Product Category: | PMIC - Voltage Regulators - Linear |
| Data Sheet: | TPS71501QDCKRQ1 |
| Description: | IC REG LIN POS ADJ 50MA SC70-5 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | PMIC - Voltage Regulators - Linear |
| PSRR | 55dB ~ 52dB (120Hz) |
| Series | Automotive, AEC-Q100 |
| Packaging | Digi-Reel® |
| Output Type | Adjustable |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 5-TSSOP, SC-70-5, SOT-353 |
| Base Part Number | TPS71501 |
| Control Features | Enable, Power Good |
| Current - Output | 50mA |
| Protection Features | Over Temperature, Reverse Polarity |
| Number of Regulators | 1 |
| Output Configuration | Positive |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Input (Max) | 24V |
| Voltage Dropout (Max) | 0.23V @ 500mA |
| Current - Supply (Max) | 5.8µA |
| Voltage - Output (Max) | 15V |
| Supplier Device Package | SC-70-5 |
| Current - Quiescent (Iq) | 4.2µA |
| Voltage - Output (Min/Fixed) | 1.2V |
In Stock 872 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
