Image is for reference only , See Product Specifications
SN74LVC14ADRG3
| Manufacturers: | Texas Instruments |
|---|---|
| Product Category: | Logic - Gates and Inverters |
| Data Sheet: | SN74LVC14ADRG3 |
| Description: | IC INVERTER SCHMITT 6CH 14SOIC |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | Logic - Gates and Inverters |
| Series | 74LVC |
| Features | Schmitt Trigger |
| Packaging | Digi-Reel® |
| Logic Type | Inverter |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
| Base Part Number | 74LVC14 |
| Number of Inputs | 6 |
| Voltage - Supply | 1.65V ~ 3.6V |
| Logic Level - Low | 0.15V ~ 0.8V |
| Logic Level - High | 1.3V ~ 2V |
| Number of Circuits | 6 |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | 14-SOIC |
| Current - Quiescent (Max) | 1µA |
| Current - Output High, Low | 24mA, 24mA |
| Max Propagation Delay @ V, Max CL | 6.2ns @ 3.3V, 50pF |
In Stock 4030 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
