Image is for reference only , See Product Specifications
PTN78000WAZT
| Manufacturers: | Texas Instruments |
|---|---|
| Product Category: | DC DC Converters |
| Data Sheet: | PTN78000WAZT |
| Description: | DC DC CONVERTER 2.5-12.6V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | DC DC Converters |
| Type | Non-Isolated PoL Module |
| Series | PTN78000W |
| Features | OCP, OTP, UVLO |
| Packaging | Digi-Reel® |
| Efficiency | 91% |
| Part Status | Active |
| Applications | ITE (Commercial) |
| Mounting Type | Surface Mount |
| Package / Case | 5-SMD Module |
| Base Part Number | PTN78000W |
| Size / Dimension | 0.75" L x 0.50" W x 0.36" H (19.1mm x 12.7mm x 9.1mm) |
| Number of Outputs | 1 |
| Voltage - Output 1 | 2.5 ~ 12.6V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Input (Max) | 36V |
| Voltage - Input (Min) | 7V |
| Current - Output (Max) | 1.5A |
In Stock 2236 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
