Image is for reference only , See Product Specifications
ISO7742DWR
| Manufacturers: | Texas Instruments |
|---|---|
| Product Category: | Digital Isolators |
| Data Sheet: | ISO7742DWR |
| Description: | DGTL ISO 5KV 4CH GEN PURP 16SOIC |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | Digital Isolators |
| Type | General Purpose |
| Series | - |
| Data Rate | 100Mbps |
| Packaging | Digi-Reel® |
| Technology | Capacitive Coupling |
| Part Status | Active |
| Channel Type | Unidirectional |
| Mounting Type | Surface Mount |
| Isolated Power | No |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) |
| Voltage - Supply | 2.25V ~ 5.5V |
| Number of Channels | 4 |
| Voltage - Isolation | 5000Vrms |
| Operating Temperature | -55°C ~ 125°C |
| Inputs - Side 1/Side 2 | 2/2 |
| Rise / Fall Time (Typ) | 2.4ns, 2.4ns |
| Supplier Device Package | 16-SOIC |
| Pulse Width Distortion (Max) | 4.9ns |
| Propagation Delay tpLH / tpHL (Max) | 16ns, 16ns |
| Common Mode Transient Immunity (Min) | 85kV/µs |
In Stock 2235 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
