Image is for reference only , See Product Specifications
ISO7421DR
| Manufacturers: | Texas Instruments |
|---|---|
| Product Category: | Digital Isolators |
| Data Sheet: | ISO7421DR |
| Description: | DGTL ISO 2.5KV GEN PURP 8SOIC |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | Digital Isolators |
| Type | General Purpose |
| Series | - |
| Data Rate | 1Mbps |
| Packaging | Digi-Reel® |
| Technology | Capacitive Coupling |
| Part Status | Active |
| Channel Type | Unidirectional |
| Mounting Type | Surface Mount |
| Isolated Power | No |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Voltage - Supply | 3.15V ~ 3.45V, 4.75V ~ 5.25V |
| Number of Channels | 2 |
| Voltage - Isolation | 2500Vrms |
| Operating Temperature | -40°C ~ 105°C |
| Inputs - Side 1/Side 2 | 1/1 |
| Rise / Fall Time (Typ) | 1ns, 1ns |
| Supplier Device Package | 8-SOIC |
| Pulse Width Distortion (Max) | 3.7ns |
| Propagation Delay tpLH / tpHL (Max) | 14ns, 14ns |
| Common Mode Transient Immunity (Min) | 25kV/µs |
In Stock 25037 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
