Image is for reference only , See Product Specifications
DRV8432DKDR
| Manufacturers: | Texas Instruments |
|---|---|
| Product Category: | PMIC - Full, Half-Bridge Drivers |
| Data Sheet: | DRV8432DKDR |
| Description: | IC BRIDGE DRIVER PAR 36HSSOP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | PMIC - Full, Half-Bridge Drivers |
| Series | - |
| Features | Status Flag |
| Interface | PWM |
| Load Type | Inductive |
| Packaging | Digi-Reel® |
| Technology | Power MOSFET |
| Part Status | Active |
| Applications | DC Motors, Stepper Motors |
| Rds On (Typ) | 110mOhm LS, 110mOhm HS |
| Mounting Type | Surface Mount |
| Package / Case | 36-BSSOP (0.433", 11.00mm Width) Exposed Pad |
| Voltage - Load | 0V ~ 52.5V |
| Base Part Number | DRV8432 |
| Fault Protection | Current Limiting, Over Temperature, Short Circuit, UVLO |
| Voltage - Supply | 10.8V ~ 13.2V |
| Output Configuration | Half Bridge (4) |
| Current - Peak Output | 12A |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | 36-HSSOP |
| Current - Output / Channel | 7A |
In Stock 4176 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
Request Quote
