CSD19531Q5A
| Manufacturers: | Texas Instruments |
|---|---|
| Product Category: | Transistors - FETs, MOSFETs - Single |
| Data Sheet: | CSD19531Q5A |
| Description: | MOSFET N-CH 100V 100A 8SON |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | Transistors - FETs, MOSFETs - Single |
| Series | NexFET™ |
| FET Type | N-Channel |
| Packaging | Cut Tape (CT) |
| Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerTDFN |
| Vgs(th) (Max) @ Id | 3.3V @ 250µA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 6.4mOhm @ 16A, 10V |
| Power Dissipation (Max) | 3.3W (Ta), 125W (Tc) |
| Supplier Device Package | 8-VSONP (5x6) |
| Gate Charge (Qg) (Max) @ Vgs | 48nC @ 10V |
| Drain to Source Voltage (Vdss) | 100V |
| Input Capacitance (Ciss) (Max) @ Vds | 3870pF @ 50V |
| Current - Continuous Drain (Id) @ 25°C | 100A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 6V, 10V |
In Stock 10373 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.77 | $1.73 | $1.70 |
