CD4053BE
| Manufacturers: | Texas Instruments |
|---|---|
| Product Category: | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Data Sheet: | CD4053BE |
| Description: | IC MUX/DEMUX TRIPLE 2X1 16DIP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Texas Instruments |
| Product Category | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Series | - |
| Crosstalk | -40dB @ 6MHz |
| Packaging | Tube |
| Part Status | Active |
| -3db Bandwidth | 30MHz |
| Package / Case | 16-DIP (0.300", 7.62mm) |
| Switch Circuit | SPDT |
| Base Part Number | 4053 |
| Charge Injection | - |
| Number of Circuits | 3 |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Supplier Device Package | 16-PDIP |
| On-State Resistance (Max) | 240Ohm |
| Voltage - Supply, Dual (V±) | ±2.5V ~ 9V |
| Switch Time (Ton, Toff) (Max) | - |
| Voltage - Supply, Single (V+) | 3V ~ 20V |
| Current - Leakage (IS(off)) (Max) | 100nA |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Channel-to-Channel Matching (ΔRon) | 5Ohm |
| Channel Capacitance (CS(off), CD(off)) | 0.2pF, 9pF |
In Stock 12856 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.52 | $0.51 | $0.50 |
