Image is for reference only , See Product Specifications
TEQ 200-4812WIR
| Manufacturers: | TRACO Power |
|---|---|
| Product Category: | DC DC Converters |
| Data Sheet: | TEQ 200-4812WIR |
| Description: | DC/DC CONVERTER 12V 216W |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | TRACO Power |
| Product Category | DC DC Converters |
| Type | Enclosed |
| Series | TEQ 20WIR (20W) |
| Approvals | CB, cULus, cURus |
| Efficiency | 89% |
| Part Status | Active |
| Applications | Industrial, ITE (Commercial), Railway |
| Mounting Type | Chassis Mount |
| Power (Watts) | 216W |
| Size / Dimension | 4.06" L x 3.50" W x 3.45" H (103.1mm x 88.9mm x 87.6mm) |
| Number of Outputs | 1 |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Isolation | 2.25kV |
| Operating Temperature | -40°C ~ 105°C |
| Voltage - Input (Max) | 75V |
| Voltage - Input (Min) | 19V |
| Current - Output (Max) | 18A |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $513.60 | $503.33 | $493.26 |
Request Quote
