Image is for reference only , See Product Specifications
TCK-045
| Manufacturers: | TRACO Power |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | TCK-045 |
| Description: | FIXED IND 56UH 700MA 400MOHM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | TRACO Power |
| Product Category | Fixed Inductors |
| Type | - |
| Series | - |
| Ratings | - |
| Features | - |
| Q @ Freq | - |
| Shielding | Unshielded |
| Tolerance | ±20% |
| Inductance | 56µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | - |
| Size / Dimension | 0.228" L x 0.205" W (5.80mm x 5.20mm) |
| DC Resistance (DCR) | 400mOhm |
| Current - Saturation | - |
| Current Rating (Amps) | 700mA |
| Height - Seated (Max) | 0.199" (5.05mm) |
| Operating Temperature | -40°C ~ 125°C |
| Frequency - Self Resonant | - |
| Inductance Frequency - Test | 1kHz |
In Stock 10 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $3.96 | $3.88 | $3.80 |
