Image is for reference only , See Product Specifications
1757829-1
| Manufacturers: | TE Connectivity Aerospace Defense and Marine |
|---|---|
| Product Category: | D-Sub Connectors |
| Data Sheet: | 1757829-1 |
| Description: | CONN D-SUB PLUG 9POS VERT SOLDER |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | TE Connectivity Aerospace Defense and Marine |
| Product Category | D-Sub Connectors |
| Color | Black |
| Series | Military, MIL-DTL-24308, AMPLIMITE 109 |
| Features | - |
| Packaging | Bulk |
| Wire Gauge | - |
| Part Status | Active |
| Termination | Solder |
| Contact Form | - |
| Contact Type | Signal |
| Mounting Type | Through Hole |
| Connector Type | Plug, Male Pins |
| Contact Finish | Gold |
| Flange Feature | Housing/Shell (Unthreaded) |
| Number of Rows | 2 |
| Voltage Rating | - |
| Backset Spacing | - |
| Connector Style | D-Sub |
| Contact Material | Brass |
| Ingress Protection | - |
| Dielectric Material | - |
| Number of Positions | 9 |
| Current Rating (Amps) | 5A |
| Operating Temperature | -55°C ~ 125°C |
| Shell Material, Finish | Steel, Yellow Chromate Plated Zinc |
| Contact Finish Thickness | 10.0µin (0.25µm) |
| Material Flammability Rating | - |
| Shell Size, Connector Layout | 1 (DE, E) |
In Stock 171 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $14.61 | $14.32 | $14.03 |
