| Manufacturer |
TE Connectivity Aerospace Defense and Marine |
| Product Category |
Coaxial Connectors (RF) |
| Series |
- |
| Features |
- |
| Includes |
6 pcs - 1 Connector, 1 Clamp Braid, 1 Clamp, 1 Contact, 1 Gasket, 1 Washer |
| Impedance |
50Ohm |
| Packaging |
Bulk |
| Body Finish |
Nickel |
| Cable Group |
RG-58, 58A, 58B, 58C, 141, 141A, 142, 142A, 142B |
| Part Status |
Active |
| Body Material |
Brass |
| Housing Color |
Silver |
| Mating Cycles |
500 |
| Mounting Type |
Free Hanging (In-Line) |
| Connector Type |
Plug, Male Pin |
| Fastening Type |
Bayonet Lock |
| Insertion Loss |
- |
| Voltage Rating |
500V |
| Connector Style |
BNC |
| Frequency - Max |
4GHz |
| Mounting Feature |
- |
| Ingress Protection |
- |
| Shield Termination |
Clamp |
| Contact Termination |
Solder |
| Dielectric Material |
Polytetrafluoroethylene (PTFE) |
| Operating Temperature |
55°C ~ 85°C |
| Center Contact Plating |
Gold |
| Center Contact Material |
Brass |
