Image is for reference only , See Product Specifications
52949
| Manufacturers: | TE Connectivity AMP Connectors |
|---|---|
| Product Category: | Terminals - Spade Connectors |
| Data Sheet: | 52949 |
| Description: | CONN SPADE TERM 16-22AWG #6 RED |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Product Category | Terminals - Spade Connectors |
| Color | Red |
| Series | Plasti-Grip |
| Features | Serrated Termination |
| Packaging | Bulk |
| Insulation | Insulated |
| Wire Gauge | 16-22 AWG |
| Part Status | Active |
| Termination | Crimp |
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 6 Stud |
| Terminal Type | Spring, Snap |
| Contact Finish | Tin |
| Contact Material | Brass |
| Length - Overall | 0.811" (20.60mm) |
| Insulation Diameter | 0.105" ~ 0.140" (2.67mm ~ 3.56mm) |
| Width - Outer Edges | 0.250" (6.35mm) |
| Length - Termination | 0.416" (10.57mm) |
| Material - Insulation | Poly-Vinyl Chloride (PVC) |
| Tongue Inside Opening | 0.140" (3.56mm) |
| Length - Ring Center to Termination | 0.250" (6.35mm) |
In Stock 4831 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.31 | $0.30 | $0.30 |
