Image is for reference only , See Product Specifications
487576-9
| Manufacturers: | TE Connectivity AMP Connectors |
|---|---|
| Product Category: | FFC, FPC (Flat Flexible) Connectors |
| Data Sheet: | 487576-9 |
| Description: | CONN FFC VERT 17POS 1.27MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Product Category | FFC, FPC (Flat Flexible) Connectors |
| Pitch | 0.050" (1.27mm) |
| Series | AMPMODU |
| Features | Zero Insertion Force (ZIF) |
| Packaging | Tube |
| Part Status | Active |
| Termination | Solder |
| Housing Color | Black |
| Mating Cycles | - |
| Mounting Type | Through Hole |
| Actuator Color | Black |
| Cable End Type | Straight |
| Contact Finish | Tin |
| Flat Flex Type | FFC |
| Voltage Rating | 150V |
| Locking Feature | Slide Lock |
| Contact Material | Phosphor Bronze |
| Actuator Material | Thermoplastic |
| FFC, FCB Thickness | 0.10mm ~ 0.31mm |
| Height Above Board | 0.310" (7.87mm) |
| Dielectric Material | Thermoplastic |
| Number of Positions | 17 |
| Current Rating (Amps) | 1A |
| Operating Temperature | -55°C ~ 105°C |
| Connector/Contact Type | Contacts, Vertical - 1 Sided |
| Contact Finish Thickness | 150.0µin (3.81µm) |
| Material Flammability Rating | - |
In Stock 1991 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.94 | $1.90 | $1.86 |
