Image is for reference only , See Product Specifications
328142
| Manufacturers: | TE Connectivity AMP Connectors |
|---|---|
| Product Category: | Terminals - Rectangular Connectors |
| Data Sheet: | 328142 |
| Description: | CONN TERM RECT 6 AWG #1/4 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Product Category | Terminals - Rectangular Connectors |
| Color | - |
| Series | Ampower |
| Features | - |
| Packaging | Bulk |
| Insulation | Non-Insulated |
| Wire Gauge | 6 AWG |
| Part Status | Active |
| Termination | Crimp, Barrel |
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 1/4 Stud |
| Tab Thickness | 0.080" (2.03mm) |
| Terminal Type | Standard |
| Contact Finish | Tin |
| Terminal Style | Single Stud Hole |
| Contact Material | Copper |
| Length - Overall | 1.410" (35.81mm) |
| Diameter - Ring ID | 0.265" (6.73mm) |
| Width - Outer Edges | 0.690" (17.53mm) |
| Diameter - Barrel ID | 0.219" (5.56mm) |
| Diameter - Barrel OD | 0.314" (7.98mm) |
In Stock 1735 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $6.14 | $6.02 | $5.90 |
Request Quote
