Image is for reference only , See Product Specifications
AV1910R112Q04
| Manufacturers: | TE Connectivity ALCOSWITCH Switches |
|---|---|
| Product Category: | Pushbutton Switches |
| Data Sheet: | AV1910R112Q04 |
| Description: | SWITCH PUSH SPST-NO 3A 250V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | TE Connectivity ALCOSWITCH Switches |
| Product Category | Pushbutton Switches |
| Type | Vandal Resistant, Illuminated |
| Series | AV19 |
| Circuit | SPST-NO |
| Features | Fixed LED Ring |
| Packaging | Tray |
| Part Status | Active |
| Actuator Type | Round, Button, Flush |
| Mounting Type | Panel Mount, Front |
| Electrical Life | 50,000 Cycles |
| Mechanical Life | 1,000,000 Cycles |
| Switch Function | Off-Mom |
| Termination Style | Solder Lug |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Voltage Rating - AC | 250V |
| Color - Actuator/Cap | Silver |
| Current Rating (Amps) | 3A (AC) |
| Operating Temperature | -20°C ~ 55°C |
| Panel Cutout Dimensions | Circular - 19.20mm Dia |
| Illumination Type, Color | LED, White |
| Illumination Voltage (Nominal) | 12 VDC |
In Stock 28 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $16.06 | $15.74 | $15.42 |
Request Quote
