Image is for reference only , See Product Specifications
TY5F
| Manufacturers: | Switchcraft Inc. |
|---|---|
| Product Category: | Circular Connectors |
| Data Sheet: | TY5F |
| Description: | CONN PLUG FM MINI XLR 5P SDR CUP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Switchcraft Inc. |
| Product Category | Circular Connectors |
| Color | Silver |
| Series | TINI Q-G® TY |
| Features | Ground |
| Packaging | Bulk |
| Shielding | - |
| Orientation | Keyed |
| Part Status | Active |
| Termination | Solder Cup |
| Applications | Audio |
| Shell Finish | Nickel |
| Cable Opening | - |
| Mounting Type | Panel Mount |
| Connector Type | Plug, Female Sockets |
| Fastening Type | Latch Lock |
| Shell Material | Brass |
| Voltage Rating | 125VAC |
| Insert Material | Polyphenylene Sulfide (PPS) |
| Shell Size, MIL | - |
| Contact Material | Beryllium Copper |
| Mounting Feature | Flange |
| Ingress Protection | - |
| Number of Positions | 5 |
| Shell Size - Insert | Mini XLR |
| Current Rating (Amps) | 4A |
| Operating Temperature | -55°C ~ 85°C |
| Contact Finish - Mating | Silver |
| Backshell Material, Plating | - |
| Material Flammability Rating | - |
| Contact Finish Thickness - Mating | - |
In Stock 34 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $14.45 | $14.16 | $13.88 |
