Image is for reference only , See Product Specifications
EN3P6MRAPCBN
| Manufacturers: | Switchcraft Inc. |
|---|---|
| Product Category: | Circular Connectors |
| Data Sheet: | EN3P6MRAPCBN |
| Description: | CONN RCPT MALE 6POS GOLD PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Switchcraft Inc. |
| Product Category | Circular Connectors |
| Color | Black |
| Series | EN3® |
| Features | - |
| Packaging | Bulk |
| Shielding | Unshielded |
| Orientation | Keyed |
| Part Status | Active |
| Termination | Circuit Board, Solder |
| Applications | General Purpose, Instrumentation, Marine, Medical |
| Shell Finish | - |
| Cable Opening | - |
| Mounting Type | Panel Mount, Through Hole, Right Angle |
| Connector Type | Receptacle, Male Pins |
| Fastening Type | Bayonet Lock |
| Shell Material | Thermoplastic |
| Voltage Rating | 250VAC/DC |
| Insert Material | Elastomer |
| Shell Size, MIL | - |
| Contact Material | Copper Alloy |
| Mounting Feature | Bulkhead - Front Side Nut |
| Ingress Protection | IP66/68 - Dust Tight, Water Resistant, Waterproof |
| Number of Positions | 6 |
| Shell Size - Insert | - |
| Current Rating (Amps) | 4A |
| Operating Temperature | -40°C ~ 65°C |
| Contact Finish - Mating | Gold |
| Backshell Material, Plating | - |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Mating | - |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $10.75 | $10.54 | $10.32 |
