Image is for reference only , See Product Specifications
A6F
| Manufacturers: | Switchcraft Inc. |
|---|---|
| Product Category: | Circular Connectors |
| Data Sheet: | A6F |
| Description: | CONN PLUG FMALE XLR 6POS SOLDER |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Switchcraft Inc. |
| Product Category | Circular Connectors |
| Color | Silver |
| Series | Q-G® A |
| Features | Backshell, Cable Clamp, Ground, Strain Relief |
| Packaging | Bulk |
| Shielding | - |
| Orientation | Keyed |
| Part Status | Active |
| Termination | Solder Cup |
| Applications | Audio, Instrumentation |
| Shell Finish | - |
| Cable Opening | 0.210" ~ 0.300" (5.33mm ~ 7.62mm) |
| Mounting Type | Free Hanging (In-Line) |
| Connector Type | Plug, Female Sockets |
| Fastening Type | Latch Lock |
| Shell Material | Stainless Steel |
| Voltage Rating | 125VAC |
| Insert Material | Polyester |
| Shell Size, MIL | - |
| Contact Material | Brass |
| Mounting Feature | - |
| Ingress Protection | - |
| Number of Positions | 6 |
| Shell Size - Insert | XLR |
| Current Rating (Amps) | 7.5A |
| Operating Temperature | - |
| Contact Finish - Mating | Silver |
| Backshell Material, Plating | Zinc, Nickel |
| Material Flammability Rating | - |
| Contact Finish Thickness - Mating | - |
In Stock 18 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $21.35 | $20.92 | $20.50 |
Request Quote
