Image is for reference only , See Product Specifications
SC75B-220
| Manufacturers: | Signal Transformer |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | SC75B-220 |
| Description: | FIXED IND 22UH 2.1A 110 MOHM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Signal Transformer |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | SC75B |
| Ratings | - |
| Q @ Freq | - |
| Packaging | Tape & Reel (TR) |
| Shielding | Unshielded |
| Tolerance | ±20% |
| Inductance | 22µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | - |
| Size / Dimension | 0.319" L x 0.287" W (8.10mm x 7.30mm) |
| DC Resistance (DCR) | 110mOhm Max |
| Current - Saturation | 1.5A |
| Current Rating (Amps) | 2.1A |
| Height - Seated (Max) | 0.217" (5.50mm) |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | - |
| Inductance Frequency - Test | 2.52MHz |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.63 | $0.62 | $0.61 |
