Image is for reference only , See Product Specifications
S2S4000F
| Manufacturers: | Sharp Microelectronics |
|---|---|
| Product Category: | Optoisolators - Triac, SCR Output |
| Data Sheet: | S2S4000F |
| Description: | OPTOISOLATOR 3.75KV TRIAC 4SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Sharp Microelectronics |
| Product Category | Optoisolators - Triac, SCR Output |
| Series | - |
| Approvals | CSA, UR |
| Packaging | Tube |
| Output Type | Triac |
| Part Status | Obsolete |
| Turn On Time | 50µs (Max) |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD |
| Number of Channels | 1 |
| Static dV/dt (Min) | 100V/µs |
| Current - Hold (Ih) | 3.5mA |
| Voltage - Isolation | 3750Vrms |
| Voltage - Off State | 600V |
| Operating Temperature | -30°C ~ 100°C |
| Zero Crossing Circuit | Yes |
| Supplier Device Package | 4-SMD |
| Voltage - Forward (Vf) (Typ) | 1.2V |
| Current - DC Forward (If) (Max) | 50mA |
| Current - LED Trigger (Ift) (Max) | 10mA |
| Current - On State (It (RMS)) (Max) | 50mA |
