Image is for reference only , See Product Specifications
PQ20RX05
| Manufacturers: | Sharp Microelectronics |
|---|---|
| Product Category: | PMIC - Voltage Regulators - Linear |
| Data Sheet: | PQ20RX05 |
| Description: | IC REG LIN POS ADJ 500MA TO220-5 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Sharp Microelectronics |
| Product Category | PMIC - Voltage Regulators - Linear |
| PSRR | 45dB (120Hz) |
| Series | - |
| Packaging | Tube |
| Output Type | Adjustable |
| Part Status | Obsolete |
| Mounting Type | Through Hole |
| Package / Case | TO-220-5 Formed Leads |
| Control Features | Enable |
| Current - Output | 500mA |
| Protection Features | Over Current, Over Temperature |
| Number of Regulators | 1 |
| Output Configuration | Positive |
| Operating Temperature | -20°C ~ 80°C |
| Voltage - Input (Max) | 24V |
| Voltage Dropout (Max) | 0.5V @ 300mA |
| Voltage - Output (Max) | 20V |
| Supplier Device Package | TO-220-5 |
| Current - Quiescent (Iq) | 8mA |
| Voltage - Output (Min/Fixed) | 3V |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
