Image is for reference only , See Product Specifications
GM5SAE65P0A
| Manufacturers: | Sharp Microelectronics |
|---|---|
| Product Category: | LED Indication - Discrete |
| Data Sheet: | GM5SAE65P0A |
| Description: | LED COOL WHITE SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Sharp Microelectronics |
| Product Category | LED Indication - Discrete |
| Color | White, Cool |
| Series | - |
| Features | - |
| Lens Size | 2.40mm Dia |
| Packaging | Digi-Reel® |
| Lens Color | - |
| Lens Style | Round with Flat Top |
| Part Status | Obsolete |
| Height (Max) | 1.90mm |
| Configuration | Standard |
| Mounting Type | Surface Mount |
| Viewing Angle | - |
| Current - Test | 20mA |
| Package / Case | 2-PLCC |
| Size / Dimension | 3.20mm L x 2.80mm W |
| Lens Transparency | - |
| Wavelength - Peak | - |
| Millicandela Rating | 2200mcd |
| Wavelength - Dominant | 6500K |
| Supplier Device Package | - |
| Voltage - Forward (Vf) (Typ) | 3.2V |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
