Image is for reference only , See Product Specifications
VN820PTTR-E
| Manufacturers: | STMicroelectronics |
|---|---|
| Product Category: | PMIC - Power Distribution Switches, Load Drivers |
| Data Sheet: | VN820PTTR-E |
| Description: | IC DRIVER HIGH SIDE 9A PPAK |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | STMicroelectronics |
| Product Category | PMIC - Power Distribution Switches, Load Drivers |
| Series | VIPower™ |
| Features | Auto Restart, Status Flag |
| Interface | On/Off |
| Packaging | Digi-Reel® |
| Input Type | Non-Inverting |
| Output Type | N-Channel |
| Part Status | Active |
| Switch Type | General Purpose |
| Rds On (Typ) | 40mOhm (Max) |
| Package / Case | TO-252-5, DPak (4 Leads + Tab), TO-252AD |
| Voltage - Load | 5.5V ~ 36V |
| Base Part Number | VN820 |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage |
| Number of Outputs | 1 |
| Output Configuration | High Side |
| Ratio - Input:Output | 1:1 |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Current - Output (Max) | 9A |
| Supplier Device Package | PPAK |
| Voltage - Supply (Vcc/Vdd) | Not Required |
In Stock 2498 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
