Image is for reference only , See Product Specifications
STGW30H65FB
| Manufacturers: | STMicroelectronics |
|---|---|
| Product Category: | Transistors - IGBTs - Single |
| Data Sheet: | STGW30H65FB |
| Description: | IGBT 650V 30A 260W TO-247 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | STMicroelectronics |
| Product Category | Transistors - IGBTs - Single |
| Series | - |
| IGBT Type | Trench Field Stop |
| Packaging | Tube |
| Input Type | Standard |
| Gate Charge | 149nC |
| Part Status | Active |
| Power - Max | 260W |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Test Condition | 400V, 30A, 10Ohm, 15V |
| Base Part Number | STGW30 |
| Switching Energy | 151µJ (on), 293µJ (off) |
| Td (on/off) @ 25°C | 37ns/146ns |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | TO-247 |
| Vce(on) (Max) @ Vge, Ic | 2V @ 15V, 30A |
| Current - Collector (Ic) (Max) | 30A |
| Current - Collector Pulsed (Icm) | 120A |
| Voltage - Collector Emitter Breakdown (Max) | 650V |
In Stock 46 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $3.42 | $3.35 | $3.28 |
