Image is for reference only , See Product Specifications
STF23NM60ND
| Manufacturers: | STMicroelectronics |
|---|---|
| Product Category: | Transistors - FETs, MOSFETs - Single |
| Data Sheet: | STF23NM60ND |
| Description: | MOSFET N-CH 600V 19.5A TO-220FP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | STMicroelectronics |
| Product Category | Transistors - FETs, MOSFETs - Single |
| Series | FDmesh™ II |
| FET Type | N-Channel |
| Packaging | Tube |
| Vgs (Max) | ±25V |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 Full Pack |
| Base Part Number | STF23 |
| Vgs(th) (Max) @ Id | 5V @ 250µA |
| Operating Temperature | 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 180mOhm @ 10A, 10V |
| Power Dissipation (Max) | 35W (Tc) |
| Supplier Device Package | TO-220FP |
| Gate Charge (Qg) (Max) @ Vgs | 70nC @ 10V |
| Drain to Source Voltage (Vdss) | 600V |
| Input Capacitance (Ciss) (Max) @ Vds | 2050pF @ 50V |
| Current - Continuous Drain (Id) @ 25°C | 19.5A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.70 | $2.65 | $2.59 |
