STD15N50M2AG
| Manufacturers: | STMicroelectronics |
|---|---|
| Product Category: | Transistors - FETs, MOSFETs - Single |
| Data Sheet: | STD15N50M2AG |
| Description: | MOSFET N-CHANNEL 500V 10A DPAK |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | STMicroelectronics |
| Product Category | Transistors - FETs, MOSFETs - Single |
| Series | Automotive, AEC-Q101, MDmesh™ M2 |
| FET Type | N-Channel |
| Packaging | Digi-Reel® |
| Vgs (Max) | ±30V |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
| Base Part Number | STD15 |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 380mOhm @ 5A, 10V |
| Power Dissipation (Max) | 85W (Tc) |
| Supplier Device Package | DPAK |
| Gate Charge (Qg) (Max) @ Vgs | 13nC @ 10V |
| Drain to Source Voltage (Vdss) | 500V |
| Input Capacitance (Ciss) (Max) @ Vds | 530pF @ 100V |
| Current - Continuous Drain (Id) @ 25°C | 10A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
In Stock 3752 pcs
