Image is for reference only , See Product Specifications
L298N
| Manufacturers: | STMicroelectronics |
|---|---|
| Product Category: | PMIC - Full, Half-Bridge Drivers |
| Data Sheet: | L298N |
| Description: | IC BRIDGE DRIVER PAR 15MULTIWATT |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | STMicroelectronics |
| Product Category | PMIC - Full, Half-Bridge Drivers |
| Series | - |
| Features | - |
| Interface | Logic |
| Load Type | Inductive |
| Packaging | Tube |
| Technology | Bipolar |
| Part Status | Active |
| Applications | DC Motors, Relays, Solenoids, Stepper Motors |
| Rds On (Typ) | - |
| Mounting Type | Through Hole |
| Package / Case | Multiwatt-15 (Vertical, Bent and Staggered Leads) |
| Voltage - Load | 4.8V ~ 46V |
| Base Part Number | L298 |
| Fault Protection | Current Limiting, Over Temperature |
| Voltage - Supply | 4.5V ~ 7V |
| Output Configuration | Half Bridge (4) |
| Current - Peak Output | 2A |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | 15-Multiwatt |
| Current - Output / Channel | - |
In Stock 4082 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $4.86 | $4.76 | $4.67 |
Request Quote
