63RX30330MG412.5X25
| Manufacturers: | Rubycon |
|---|---|
| Product Category: | Aluminum Electrolytic Capacitors |
| Data Sheet: | 63RX30330MG412.5X25 |
| Description: | CAP ALUM 330UF 20% 63V RADIAL |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Rubycon |
| Product Category | Aluminum Electrolytic Capacitors |
| Series | RX30 |
| Ratings | AEC-Q200 |
| Impedance | 72 mOhms |
| Packaging | Cut Tape (CT) |
| Tolerance | ±20% |
| Capacitance | 330µF |
| Part Status | Active |
| Applications | Automotive |
| Lead Spacing | 0.197" (5.00mm) |
| Polarization | Polar |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Voltage - Rated | 63V |
| Lifetime @ Temp. | 4000 Hrs @ 130°C |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 1.063" (27.00mm) |
| Operating Temperature | -40°C ~ 130°C |
| Surface Mount Land Size | - |
| Ripple Current @ Low Frequency | 700mA @ 120Hz |
| Ripple Current @ High Frequency | 1A @ 100kHz |
| ESR (Equivalent Series Resistance) | - |
In Stock 1143 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.46 | $1.43 | $1.40 |
