Image is for reference only , See Product Specifications
6.3TRV6800M16X21.5
| Manufacturers: | Rubycon |
|---|---|
| Product Category: | Aluminum Electrolytic Capacitors |
| Data Sheet: | 6.3TRV6800M16X21.5 |
| Description: | CAP ALUM 6800UF 20% 6.3V SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Rubycon |
| Product Category | Aluminum Electrolytic Capacitors |
| Series | TRV |
| Ratings | - |
| Impedance | 41 mOhms |
| Packaging | Digi-Reel® |
| Tolerance | ±20% |
| Capacitance | 6800µF |
| Part Status | Active |
| Applications | General Purpose |
| Lead Spacing | - |
| Polarization | Polar |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Voltage - Rated | 6.3V |
| Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 0.866" (22.00mm) |
| Operating Temperature | -40°C ~ 105°C |
| Surface Mount Land Size | 0.669" L x 0.669" W (17.00mm x 17.00mm) |
| Ripple Current @ Low Frequency | 1.2A @ 120Hz |
| Ripple Current @ High Frequency | 2A @ 100kHz |
| ESR (Equivalent Series Resistance) | - |
In Stock 225 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
