Image is for reference only , See Product Specifications
35LSW47000MNB51X98
| Manufacturers: | Rubycon |
|---|---|
| Product Category: | Aluminum Electrolytic Capacitors |
| Data Sheet: | 35LSW47000MNB51X98 |
| Description: | CAP ALUM 47000UF 20% 35V SCREW |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Rubycon |
| Product Category | Aluminum Electrolytic Capacitors |
| Series | LSW |
| Ratings | - |
| Packaging | Bulk |
| Tolerance | ±20% |
| Capacitance | 47000µF |
| Part Status | Active |
| Applications | General Purpose |
| Lead Spacing | 0.858" (21.80mm) |
| Polarization | Polar |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Voltage - Rated | 35V |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Size / Dimension | 2.008" Dia (51.00mm) |
| Height - Seated (Max) | 3.976" (101.00mm) |
| Operating Temperature | -40°C ~ 105°C |
| Surface Mount Land Size | - |
| Ripple Current @ Low Frequency | 9.9A @ 120Hz |
| Ripple Current @ High Frequency | 10.692A @ 10kHz |
| ESR (Equivalent Series Resistance) | - |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $26.70 | $26.17 | $25.64 |
