| Manufacturer |
Red Lion Controls |
| Product Category |
Controllers - Process, Temperature |
| Type |
Process, Temperature Controller (RTD, Type B, C, E, J, K, N, R, S, T) |
| Series |
PAX2 |
| Features |
Excitation Supply, Heater Fault Detection |
| Input Range |
-200°C ~ 2315°C, ±2A, ±200VDC |
| Output Type |
Option Cards Available |
| Part Status |
Active |
| Display Type |
LCD - Tri Color Characters, Backlight |
| Mounting Type |
Panel Mount |
| Communications |
Option Cards Available |
| Control Method |
On/Off, Proportional (PID) |
| Voltage - Supply |
40 ~ 250VAC, 21.6 ~ 250VDC |
| Termination Style |
Screw Terminal |
| Ingress Protection |
IP65 - Dust Tight, Water Resistant |
| Operating Temperature |
0°C ~ 50°C |
| Panel Cutout Dimensions |
Rectangular - 92.00mm x 45.00mm |
| Display Characters - Height |
0.512" (13.00mm), 0.441" (11.20mm) |
| Number of Characters Per Row |
4, 4 |
