Image is for reference only , See Product Specifications
R-78B6.5-1.0L
| Manufacturers: | RECOM Power |
|---|---|
| Product Category: | DC DC Converters |
| Data Sheet: | R-78B6.5-1.0L |
| Description: | DC DC CONVERTER 6.5V 6.5W |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | RECOM Power |
| Product Category | DC DC Converters |
| Type | Linear Regulator Replacement |
| Series | INNOLINE R-78B-1.0 |
| Features | OTP, SCP |
| Packaging | Tube |
| Efficiency | 94% |
| Part Status | Active |
| Applications | ITE (Commercial), Medical |
| Mounting Type | Through Hole, Right Angle |
| Power (Watts) | 6.5W |
| Package / Case | 3-SIP Module |
| Control Features | - |
| Size / Dimension | 0.69" L x 0.45" W x 0.33" H (17.5mm x 11.5mm x 8.5mm) |
| Number of Outputs | 1 |
| Voltage - Output 1 | 6.5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Input (Max) | 32V |
| Voltage - Input (Min) | 9V |
| Current - Output (Max) | 1A |
In Stock 172 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $9.67 | $9.48 | $9.29 |
