Image is for reference only , See Product Specifications
PF0464.602NL
| Manufacturers: | Pulse Electronics Power |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | PF0464.602NL |
| Description: | FIXED IND 6UH 3.2A 33 MOHM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Pulse Electronics Power |
| Product Category | Fixed Inductors |
| Type | - |
| Series | PF0464NL |
| Ratings | - |
| Features | - |
| Q @ Freq | - |
| Packaging | Tray |
| Shielding | Shielded |
| Tolerance | ±20% |
| Inductance | 6µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | - |
| Size / Dimension | 0.283" L x 0.283" W (7.20mm x 7.20mm) |
| DC Resistance (DCR) | 33mOhm Max |
| Current - Saturation | 2.25A |
| Current Rating (Amps) | 3.2A |
| Height - Seated (Max) | 0.118" (3.00mm) |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | 40MHz |
| Inductance Frequency - Test | 100kHz |
In Stock 210 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.47 | $1.44 | $1.41 |
