Image is for reference only , See Product Specifications
PA4320.223NLT
| Manufacturers: | Pulse Electronics Power |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | PA4320.223NLT |
| Description: | FIXED IND 22UH 5.6A 30 MOHM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Pulse Electronics Power |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | PA4320 |
| Ratings | - |
| Features | - |
| Q @ Freq | - |
| Packaging | Digi-Reel® |
| Shielding | Shielded |
| Tolerance | ±20% |
| Inductance | 22µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | - |
| Size / Dimension | 0.472" L x 0.472" W (12.00mm x 12.00mm) |
| DC Resistance (DCR) | 30mOhm Max |
| Current - Saturation | 6.8A |
| Current Rating (Amps) | 5.6A |
| Height - Seated (Max) | 0.402" (10.20mm) |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | - |
| Inductance Frequency - Test | 100kHz |
In Stock 1492 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
