Image is for reference only , See Product Specifications
3274116
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Specialized |
| Data Sheet: | 3274116 |
| Description: | DISTRIBUTION BLOCK VIOLET |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Specialized |
| Type | Middle |
| Length | 1.110" (28.19mm) |
| Series | CLIPLINE PTFIX |
| Features | - |
| Part Status | Active |
| Height (Max) | 1.299" (33.00mm) |
| Current - IEC | 24A |
| Housing Color | Violet |
| Mounting Type | DIN Rail |
| Voltage - IEC | 500V |
| Number of Levels | 3 |
| Stripping Length | 10mm |
| Terminal - Width | 15.6mm |
| Termination Style | Push In, Spring |
| Number of Positions | 6 |
| Material - Insulation | Polyamide (PA), Nylon |
| Operating Temperature | - |
| Wire Gauge or Range - AWG | 14-26 AWG |
| Wire Gauge or Range - mm² | 0.14-4mm² |
| Material Flammability Rating | UL94 V-0 |
In Stock 20 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.23 | $2.19 | $2.14 |
