Image is for reference only , See Product Specifications
3273068
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Specialized |
| Data Sheet: | 3273068 |
| Description: | DISTRIBUTION BLOCK BLUE |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Specialized |
| Type | Middle |
| Length | 2.287" (58.10mm) |
| Series | CLIPLINE PTFIX |
| Features | - |
| Part Status | Active |
| Current - UL | 5A |
| Height (Max) | 1.559" (39.60mm) |
| Voltage - UL | 600V |
| Current - IEC | 24A |
| Housing Color | Blue |
| Mounting Type | DIN Rail |
| Voltage - IEC | 500V |
| Number of Levels | 4 |
| Stripping Length | 12mm |
| Terminal - Width | 28.6mm |
| Termination Style | Push In, Spring |
| Number of Positions | 7 |
| Material - Insulation | Polyamide (PA), Nylon |
| Operating Temperature | - |
| Wire Gauge or Range - AWG | 8-20 AWG |
| Wire Gauge or Range - mm² | - |
| Material Flammability Rating | UL94 V-0 |
In Stock 13 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.82 | $2.76 | $2.71 |
