Image is for reference only , See Product Specifications
3207908
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Din Rail, Channel |
| Data Sheet: | 3207908 |
| Description: | CONN TERM BLK DISCONN 10-24AWG |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Din Rail, Channel |
| Type | Disconnect |
| Color | Black |
| Series | CLIPLINE PT |
| Features | LED |
| Fuse Type | 5mm x 20mm |
| Part Status | Active |
| Voltage - UL | - |
| Current - IEC | 6.3A |
| Voltage - IEC | 60V |
| Disconnect Type | Fuse, Lever |
| Number of Levels | 1 |
| Stripping Length | 10mm |
| Terminal - Width | 6.2mm |
| Termination Style | Push In, Spring |
| Number of Positions | 2 |
| Material - Insulation | Polyamide (PA), Nylon |
| Wire Gauge or Range - AWG | 10-24 AWG |
| Wire Gauge or Range - mm² | 0.2-4mm² |
| Material Flammability Rating | UL94 V-0 |
In Stock 35 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $16.65 | $16.32 | $15.99 |
