Image is for reference only , See Product Specifications
3045457
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | 3045457 |
| Description: | TERM BLOCK PLUG 7POS 90DEG |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Plug, Female Sockets |
| Color | Gray |
| Pitch | - |
| Series | CLIPLINE COMBI UPBV |
| Features | - |
| Packaging | Bulk |
| Screw Size | M3 |
| Part Status | Active |
| Current - UL | 20A |
| Voltage - UL | 600V |
| Current - IEC | 24A |
| Mounting Type | Free Hanging (In-Line) |
| Voltage - IEC | 500V |
| Torque - Screw | 0.5-0.6 Nm (4.4-5.3 Lb-In) |
| Plug Wire Entry | 90° |
| Contact Material | - |
| Number of Levels | 1 |
| Insulation Height | 1.850" (47.00mm) |
| Termination Style | Screw |
| Wire Strip Length | 9mm |
| Header Orientation | - |
| Ingress Protection | - |
| Contact Tail Length | - |
| Dielectric Material | Polyamide (PA), Nylon |
| Number of Positions | 7 |
| Positions Per Level | 7 |
| Contact Mating Finish | - |
| Operating Temperature | - |
| Wire Gauge or Range - AWG | 12-26 AWG |
| Wire Gauge or Range - mm² | 0.14-4mm² |
| Material Flammability Rating | UL94 V-0 |
In Stock 21 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $8.38 | $8.21 | $8.05 |
