Image is for reference only , See Product Specifications
3044584
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Din Rail, Channel |
| Data Sheet: | 3044584 |
| Description: | CONN TERM BLK FEED THRU 10-26AWG |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Din Rail, Channel |
| Type | Feed Through |
| Color | Blue |
| Series | CLIPLINE UT |
| Features | - |
| Fuse Type | - |
| Part Status | Active |
| Current - UL | 30A |
| Voltage - UL | 150V |
| Current - IEC | 32A |
| Voltage - IEC | 500V |
| Disconnect Type | - |
| Number of Levels | 1 |
| Stripping Length | 9mm |
| Terminal - Width | 6.2mm |
| Termination Style | Screw |
| Number of Positions | 4 |
| Material - Insulation | Polyamide (PA), Nylon |
| Wire Gauge or Range - AWG | 10-26 AWG |
| Wire Gauge or Range - mm² | 0.14-6mm² |
| Material Flammability Rating | UL94 V-0 |
In Stock 1212 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.59 | $2.54 | $2.49 |
