Image is for reference only , See Product Specifications
3036343
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Din Rail, Channel |
| Data Sheet: | 3036343 |
| Description: | CONN TERM BLK DISCONN 12-28AWG |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Din Rail, Channel |
| Type | Disconnect |
| Color | Gray |
| Series | CLIPLINE ST |
| Features | - |
| Fuse Type | - |
| Part Status | Active |
| Current - UL | 16A |
| Voltage - UL | 600V |
| Current - IEC | 20A |
| Voltage - IEC | 400V |
| Disconnect Type | Switch, Knife |
| Number of Levels | 1 |
| Stripping Length | 10mm |
| Terminal - Width | 5.2mm |
| Termination Style | Push In, Spring |
| Number of Positions | 2 |
| Material - Insulation | Polyamide (PA), Nylon |
| Wire Gauge or Range - AWG | 12-28 AWG |
| Wire Gauge or Range - mm² | 0.08-4mm² |
| Material Flammability Rating | UL94 V-0 |
In Stock 538 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $5.56 | $5.45 | $5.34 |
