Image is for reference only , See Product Specifications
3011067
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Din Rail, Channel |
| Data Sheet: | 3011067 |
| Description: | CONN TERM BLK DISCONN 14-30AWG |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Din Rail, Channel |
| Type | Disconnect, Feed Through, Isolated |
| Color | Gray |
| Series | CLIPLINE VIOK |
| Features | - |
| Fuse Type | - |
| Part Status | Active |
| Current - UL | 15A |
| Voltage - UL | 300V |
| Current - IEC | 24A |
| Voltage - IEC | 250V |
| Disconnect Type | Open |
| Number of Levels | 4; 1 Grounded |
| Stripping Length | 8mm |
| Terminal - Width | 6.2mm |
| Termination Style | Screw |
| Number of Positions | 9 |
| Material - Insulation | Polyamide (PA), Nylon |
| Wire Gauge or Range - AWG | 14-30 AWG |
| Wire Gauge or Range - mm² | 0.2-4mm² |
| Material Flammability Rating | UL94 V-2 |
In Stock 4 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $21.40 | $20.97 | $20.55 |
