3010110
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Din Rail, Channel |
| Data Sheet: | 3010110 |
| Description: | CONN TERM BLK FEED THRU 300 MCM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Din Rail, Channel |
| Type | Feed Through |
| Color | Gray |
| Series | CLIPLINE UKH |
| Features | - |
| Fuse Type | - |
| Part Status | Active |
| Current - UL | 285A |
| Voltage - UL | 600V |
| Current - IEC | 309A |
| Voltage - IEC | 1000V |
| Disconnect Type | - |
| Number of Levels | 1 |
| Stripping Length | 40mm |
| Terminal - Width | 31.0mm |
| Termination Style | Screw |
| Number of Positions | 2 |
| Material - Insulation | Polyamide (PA), Nylon |
| Wire Gauge or Range - AWG | 300MCM (kcmil)-2 AWG |
| Wire Gauge or Range - mm² | 35-150mm² |
| Material Flammability Rating | UL94 V-0 |
In Stock 13 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $77.05 | $75.51 | $74.00 |
