Image is for reference only , See Product Specifications
1989764
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | 1989764 |
| Description: | TERM BLOCK 4POS 45DEG 2.5MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Green |
| Pitch | 0.098" (2.50mm) |
| Series | COMBICON PTSA |
| Current | 2A |
| Voltage | 300V |
| Features | - |
| Packaging | Bulk |
| Wire Gauge | 20-26 AWG |
| Part Status | Active |
| Screw Thread | - |
| Mounting Type | Through Hole |
| Torque - Screw | - |
| Number of Levels | 1 |
| Wire Termination | Screwless - Spring Cage, Tension Clamp |
| Mating Orientation | 45° (135°) Angle with Board |
| Dielectric Material | Polyamide (PA), Nylon |
| Positions Per Level | 4 |
| Operating Temperature | -40°C ~ 85°C |
| Clamp Material - Plating | - |
| Screw Material - Plating | - |
| Contact Material - Plating | - |
In Stock 597 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.58 | $0.57 | $0.56 |
