Image is for reference only , See Product Specifications
1929546
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | 1929546 |
| Description: | TERM BLK 3P SIDE ENT 12.7MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Green |
| Pitch | 0.500" (12.70mm) |
| Series | COMBICON MKDSP |
| Current | 60A |
| Voltage | 600V |
| Features | Interlocking (Side) |
| Packaging | Bulk |
| Wire Gauge | 6-20 AWG |
| Part Status | Active |
| Screw Thread | M4 |
| Mounting Type | Through Hole |
| Torque - Screw | 1.2-1.5 Nm (10.6-13.3 Lb-In) |
| Number of Levels | 1 |
| Wire Termination | Screw - Rising Cage Clamp |
| Mating Orientation | Horizontal with Board |
| Dielectric Material | Polyamide (PA), Nylon |
| Positions Per Level | 3 |
| Operating Temperature | - |
| Clamp Material - Plating | - |
| Screw Material - Plating | - |
| Contact Material - Plating | - |
In Stock 43 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $16.64 | $16.31 | $15.98 |
